Find your perfect power solution

Use our quick finder for the best way to power your camera.

Let's get started!

Simply select your camera brand and model to discover your perfect Anton/Bauer power solution.



Runtime Calculator

Select your device and additional accessory power consumption

Brand
Model
?

Depending on you addition accessories, which you can power via D-Tap or USB, the power consuption increases.
Below some accessories examples:
SmallHD 502 - 6 Wh
Teradek Bolt Pro - 4.5 Wh

Input Accessory Power Consumption (Wh)
Total Power Consumption
Wh

Power Solutions for any Production Demands

Our three cine product lines provide the perfect power solutions for the cine industry.

  • DIONIC XT is a 14.4V, 12 amp power solution to meet the power requirements for your camera and accessories. Available in 99Wh and 156Wh.
  • DIONIC 26V is a 26V,  12 amp power solution to run power hungry cameras and lights. Available in 99Wh and 250Wh.
  • VCLX NM2 is a 14.4V, 28V and 48V 600Wh NiMH battery that provides simultaneous multi outputs and is ideal for high current applications

*Runtime based on DIONIC XT 150
**@50% Output, powered by 2x DIONIC XT 99Wh batteries.
***@50% Output, powered by 2x DIONIC XT 240Wh batteries.


DIONIC 26V

DIONIC 26V Designed for power-hungry devices, the DIONIC 26V Gold Mount Plus and B-Mount battery systems are a dedicated solution designed to power the high-performance production equipment needed to meet the demanding cinematography standards of today. A native 26V battery with continuous 12A current delivers over 300W of consistent power means you can run large LED panels for longer, producing hours of full intensity creative lighting or drive power-hungry cine cameras or high-speed cine cameras.

  • 250Wh or 99Wh lithium-ion battery
  • 12A continuous draw (20A peak, 75A inrush)
  • Built-in LCD fuel gauge shows runtime and charge capacity

Explore Dionic 26V

Go Native or Get Regulated


DIONIC XT

Peak performance in compact form. For demanding cinematographers, DIONIC XT is the gold standard for high-performance, consistently reliable mobile power in temperatures from -20C to 60C (-4F to 140F). Delivering 12 amps of constant current to power cameras and accessories simultaneously, and with sophisticated charging technology extending its lifecycle to provide the same consistent level of power throughout its life, DIONIC XT is the perfect choice where dependable power is mission critical.

  • 156Wh or 99Wh lithium-ion battery
  • Gold Mount or V-Mount options
  • 12A continuous draw (20A peak, 75A inrush)
  • P-Tap and Smart USB ports
  • Backlit multifunction LCD display
  • >1000 cycle life (flat capacity curve)

Explore The Dionic XT


VCLX NM2

The Next Generation Of VCLX

With unique Multi-Voltage Output the VCLX NM2 is the perfect all-in-one battery solution for power hungry cameras, monitors, lights and more. One XLR3 and two XLR4 connectors provide multiple high current output delivering consistent 24A current at 14.4V, 16A at 28V or 12A at 48V from the 600Wh NiMH battery.

  • Accurate Intelligence - Monitor remaining runtime, charge time and active power draw at a glance with the 2.4” color LCD screen.
  • Fully Charged In 5 Hours - The VCLX NM2 now charges twice as fast as the previous VCLX. The VCLX 2 magnetic charger can charge the battery from 0-100% in just 5 hours
  • VCLX NM2 is a 14.4V, 28V and 48V 600Wh NiMH battery that provides simultaneous multi outputs and is ideal for high current applications

Explore The VCLX NM2


CINE VCLX

The Anton Bauer CINE VCLX Battery is a 14.4V and 28V NiMH battery that provides dual simultaneous outputs and is ideal for high current applications. Power output is via two 4-pin XLR connectors for 14.4V and one 3-pin XLR connector for 28V.

  • Integral RealTime LCD - Accurately displays the percentage of remaining battery capacity at all times.
  • Multi-Voltage Output - The multi-voltage output, both 14.4 volt and 28 volt makes this battery unique, making it the perfect application for most film cameras.
  • High Current Output - Allows for 20 amp current drawn from 14.4 volt outputs and 12 amp draw from 28 volt outputs.

Explore The Cine VCLX



AntonBauer Cine battery comparison table - comparing Dionic XT, Dionic 26V, VCLX & VCLX NM2


Product Overview

The DIONIC battery series is a powerful and durable Lithium-ion power solution for aspiring filmmakers, complementing cameras including Red, Panasonic, Sony, Blackmagic, ARRI, & Canon.


DIONIC XT 90 (V-Mount)

  • Mount: V-Mount
  • Capacity: 99Wh
  • Amperage: 12A
  • Estimated Life: 1200 Cycles
  • P-Tap Connections: 1
  • USB Connections: 1
  • Weight: 0.8kg / 1.76lbs
  • Dimensions: 55 X 130 X 97mm / 2.1 X 5.1 X 3.8in
SHOW PRODUCT DETAILS

DIONIC XT 90 (Gold Mount)

  • Mount: Gold Mount
  • Capacity: 99Wh
  • Amperage: 12A
  • Estimated Life: 1200 Cycles
  • P-Tap Connections: 1
  • USB Connections: 1
  • Weight: 0.8kg / 1.76lbs
  • Dimensions: 55 X 130 X 97mm / 2.1 X 5.1 X 3.8in
Show Product Details

DIONIC XT 150 (V-Mount)

  • Mount: V-Mount
  • Capacity: 156Wh
  • Amperage: 12A
  • Estimated Life: 1200 Cycles
  • P-Tap Connections: 1
  • USB Connections: 1
  • Weight: 1.1kg / 2.4lbs
  • Dimensions: 70 X 130 X 97mm / 2.7 X 5.1 X 3.8in
SHOW PRODUCT DETAILS

DIONIC XT 150 (Gold Mount)

  • Mount: V-Mount and Gold Mount
  • Capacity: 156Wh
  • Amperage: 12A
  • Estimated Life: 1200 Cycles
  • P-Tap Connections: 1
  • USB Connections: 1
  • Weight: 1.1kg / 2.4lbs
  • Dimensions: 70 X 130 X 97mm / 2.7 X 5.1 X 3.8in
Show Product Details
Dionic 26V 98Wh B-Mount Battery

DIONIC 26V 98Wh (B-Mount)

  • Mount: B-Mount
  • Capacity: 99Wh
  • Amperage: 12A Constant
  • Estimated Life: 1000 Cycles
  • P-Tap Connections: 0
  • USB Connections: 0
  • Weight: 0.93kg / 2.05lbs
  • Dimensions: 71 X 131 X 99mm / 2.8 X 5.2 X 3.9in
Show Product Details
8675-0155_image_1_Dionic 26V 100.png

DIONIC 26V 98Wh (Gold Mount Plus)

  • Mount: Gold Mount Plus
  • Capacity: 99Wh
  • Amperage: 12A Constant
  • Estimated Life: 1000 Cycles
  • P-Tap Connections: 0
  • USB Connections: 0
  • Weight: 0.93kg / 2.05lbs
  • Dimensions: 71 X 131 X 99mm / 2.8 X 5.2 X 3.9in
SHOW PRODUCT DETAILS
Dionic 26V 240Wh B-Mount Battery

DIONIC 26V 240Wh (B-Mount)

  • Mount: B-Mount
  • Capacity: 250Wh
  • Amperage: 12A Constant
  • Estimated Life: 1000 Cycles
  • P-Tap Connections: 0
  • USB Connections: 0
  • Weight: 1.36kg / 3lbs
  • Dimensions: 87 X 131 X 99mm / 3.4 X 5.2 X 3.9in
View Full Product Details
8675-0156_image_1_Dionic 26V 240.png

DIONIC 26V 240Wh (Gold Mount Plus)

  • Mount: Gold Mount Plus
  • Capacity: 250Wh
  • Amperage: 12A Constant
  • Estimated Life: 1000 Cycles
  • P-Tap Connections: 0
  • USB Connections: 0
  • Weight: 1.36kg / 3lbs
  • Dimensions: 87 X 131 X 99mm / 3.4 X 5.2 X 3.9in
SHOW PRODUCT DETAILS
VCLX NM2 - Transparent Background.png

VCLX NM2

  • Capacity: 600Wh
  • Chemistry: Nickel Metal Hydride
  • Amperage: 24A
  • Camera interface: 2 x XLR4 (14.4V) 1 x XLR3 Selectable 28V at 16A or 48V at 12A
  • P-Tap Connections: 0
  • USB Connections: 1
  • Weight: 13.3kg / 29.35lbs
  • Dimensions: 330 X 255 X 153mm / 12.99 X 10.04 X 6.02 in
Show product details

VCLX

  • Capacity: 630Wh
  • Chemistry: Nickel Metal Hydride
  • Amperage: 20A
  • Camera interface: 4-Pin XLR (14.4v) 3-Pin XLR (28v)
  • P-Tap Connections: 0
  • USB Connections: 0
  • Weight: 11.30 kg / 24.86 lb
  • Dimensions: 324 X 254 X 138 mm / 12.64 X 9.91 X 5.38 in
SHOW PRODUCT DETAILS
